THE DOMINO™
DIFFERENCE

A Bluetooth® mesh, hub-free wireless control solution with embedded motion and daylight sensors in many in-stock fixtures.

DOMINO CONTROLS

DOMINO FIXTURES

EXPLORE THE DOMINO DIFFERENCE

SATCO | NUVO’s Domino™ NLC is a Bluetooth® mesh, hub-free wireless control solution with embedded motion and daylight sensors in many in-stock fixtures. With additional components like external controllers, keypads, and sensors Domino will be able to control not just SATCOINUVO lighting but virtually any lighting fixture.

Capabilities extend beyond simple occupancy/vacancy, daylight harvesting, scheduling and scene setting for both interior and exterior fixtures, to advanced IoT analytics platforms that can track occupancy status for space utilization, wayfinding and even critical asset tracking.

Backed up by world class SATCO technical support and service with Domino enabled product in stock we are now the best solution available for commercial lighting controls.
Energy Efficient
Meets ALL energy code and DLC requirements to qualify for maximum available energy incentives
Empowered
Intuitive app with user prompts to guide set up and use
Embedded Wireless Technology
Mesh sensors simplifies installation and saves time
Effective
Multi-function expanded configurations solve virtually any control application
Encrypted
128-bit AES signal encryption ensures maximum system security
Expandable
Unlimited number of zones for any size facility with project-level coordination and enhanced IoT analytics for space utilization, way finding and critical asset tracking capabilities
Economical
Less expensive system and set up with all items available in stock
Enhanced
By world-class SATCO Service and Support

HOW DOES IT WORK?

Domino™ offers a complete array of control modules for all load types to control virtually any fixture.
  • 2.4 GHz Bluetooth® mesh hubless system topography with encrypted signals

  • Hubless technology eliminates a potential point of failure and also enables enhanced addressable control of individual fixtures

  • Enhanced app design includes prompts for system updates and helpful project management tools (Domino Commander for more than 100 components)—helps you keep all elements up to date on firmware

  • Emergency zone controllers to meet UL 924 requirements

  • No Wi-Fi needed for initial setup

  • Embedded motion and daylight sensors in most luminaire types for interior and exterior applications

  • Expert CLSD product specialists available for service and support

  • Long-life battery-operated keypads for true wireless operation

FEATURES AND CAPABILITIES

Meet all energy code requirements, including:
  • Occupancy/Vacancy Sensing to shut off lighting in unoccupied spaces

  • Daylight harvesting—dimming light near window spaces and under skylights based on ambient natural light levels

  • Manual controls—keypads that can switch different loads of lights on and off, dim individual or groups of lights, set scenes, and control CCT if desired

  • Scheduling—set off times for interior or exterior spaces based on hours of operation

  • Control receptacles for automatic shutoff (to meet new energy code requirements)

  • Exterior photosensor and motion sensing control for site lighting

  • Addressable control of individual fixtures

  • Energy usage monitoring and reporting

  • Battery backed-up real-time clock for power outages

Expanded capabilities:
  • Circadian rhythm programming for CCT controllable fixtures

  • Domino™ app provides a confirming QR code showing system is programmed

  • Integration with external (HVAC/BMS/EMS) systems for setback control or energy monitoring

  • Enable integration with enterprise-wide software for advanced IoT analytics such as space utilization reporting, wayfinding, and critical asset tracking

DOMINO APP

Domino™ luminaires offer limitless configuration possibilities, allowing you to create custom lighting solutions for any application. You can create zones with up to 100 nodes, group fixtures for flexible control, and set up lighting scenes with the Domino app or connected wall switches.

The system also includes occupancy/vacancy sensors with adjustable light levels and time-off controls, advanced daylight harvesting technology, and task/trim tuning for optimized light levels. You can even set up schedules to match your specific needs and save energy.
